Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV135/1211
- Cylinder Type: Standard / Vented
- Cylinder height: 1200mm
- Cylinder Diameter: 450mm
- Capacity: 135 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV144/1312
- Cylinder Type: Standard / Vented
- Cylinder height: 1400mm
- Cylinder Diameter: 450mm
- Capacity: 144 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV160/1413
- Cylinder Type: Standard / Vented
- Cylinder height: 1550mm
- Cylinder Diameter: 450mm
- Capacity: 160 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV200/1514
- Cylinder Type: Standard / Vented
- Cylinder height: 1850mm
- Cylinder Diameter: 450mm
- Capacity: 200 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV250/1615
- Cylinder Type: Standard / Vented
- Cylinder height: 1800mm
- Cylinder Diameter: 500mm
- Capacity: 250 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV300/1716
- Cylinder Type: Standard / Vented
- Cylinder height: 2000mm
- Cylinder Diameter: 500mm
- Capacity: 300 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
Telford Tristar Thermal Store Open-Vented Cylinders Copper Blue is designed for installations with vented heat sources and vented heating systems only. All stores come with a blend valve/shock arrestor factory fitted and a 3kw immersion as a backup. This thermal store has been designed for fitting in situations where the running of an overflow or discharge pipe would be difficult or impractical, for example, flats/apartments. The filling of the unit is achieved by an integral filling loop which is disconnected from the mains water when the correct water level is attained. This cylinder is really a magical thing that beautifies your place to another level.
Key Features:
- Available in stainless steel or copper
- Direct, indirect or twin coil options
- Supplies mains pressure hot water & high flow rates
- Up to 3 bar max pressure / 15 litres per minute domestic flow rate
- Top-up stored water annually
- No pump or overflow pipes required
- Integral parts easily accessed
- Steel casing with white ï¬nish
- 2 x factory-ï¬tted 3kW immersion heaters
- Fully pre-plumbed ready to install
- Fully insulated to minimise any heat loss
- Domestic hot blended set to 47°C
- 22mm non-scaling ribbed heat exchanger coil
- Over-fill sensor & domestic safety shut-off valve
- No external F&E tank needed
- Exempt from G3 of the Building Regulations
- 5 Year Warranty* if the cylinder is registered and serviced annually
Technical Specifications:
- Brand: Telford
- Product Code: TSV115/1110
- Cylinder Type: Standard / Vented
- Cylinder height: 1050mm
- Cylinder Diameter: 450mm
- Capacity: 115 litre
- Immersion Heater Rating: 3 Kw
- Orientation: Vertical
- Material: Copper
- Colour: Blue
